KITS

MechBlock kits contain an assortment of components that will provide fixturing, motion control, and prototyping solutions to your lab. We recommend starting here if you are a first time user of MechBlocks. Contact us for more informtation.

IMPORTANT NOTE: MechBlocks are patent pending. CAD files and drawings are provided for informational purposes only. CAD file downloads are restricted to those logged into the site. If you don't already have an account, creating an account is fast and free. Check out our privacy policy and terms & conditions.

M-S-012

The M-S-012 is our premiumkit that contains an assortment of blocks, clamps, contact plates, thread inserts, leaf springs, tools, and hardware. Pair it with a few actuators and you can build most of the assemblies on the site.

M-S-012zoom-icon Zoom

 cad-icon STEP Files (Restricted - Login to Access)
 draw-icon PDF Drawings
 Price each ................ $3000
 Item QTY
 B11-5-5-N 12
 B11-3-3-N 5
 B11-5-1-N 16
 B11-3-1-N 6
 B11-2-1-N 6
 B11-1-1-N 4
 B10-5-0.25-EC 16
 B10-1-0.25-EC 16
 C11-1.5-9.5-N 3
 CP10-1-0.5-FL 3
 T11-1-M4 100
 W11-1-M4 50
 LS10-5-1-300-N 20
 Thread insert holder magnets 10
 M3 washers 3
 Item QTY
 M3 x 14 mm screw 3
 M4 large-diameter washers 100
 M4 small-diameter washers 25
 M4 x 10 mm screw 50
 M4 x 12 mm screw 50
 M4 x 16 mm screw 50
 M4 x 20 mm screw 50
 M4 x 25 mm screw 40
 M4 x 30 mm screw 40
 M4 x 35 mm screw 25
 M4 x 40 mm screw 25
 M4 x 45 mm screw 20
 M4 x 50 mm screw 20
 2, 2.5, and 3 mm hex keys 1 ea.
 2, 2.5, and 3 mm hex drivers 1 ea.

M-S-042

The M-S-042 is a full laboratory kit. Like the M-S-012, it contains an assortment of blocks, clamps, contact plates, thread inserts, leaf springs, and hardware - but 4X the quantity. We recommend adding actuators for complete motion control capabilities.

M-S-042zoom-icon Zoom

 cad-icon STEP Files (Restricted - Login to Access)
 draw-icon PDF Drawings
 Price each ................ $10,850
 Item QTY
 B11-5-5-N 48
 B11-3-3-N 20
 B11-5-1-N 64
 B11-3-1-N 24
 B11-2-1-N 24
 B11-1-1-N 16
 B10-5-0.25-EC 64
 B10-1-0.25-EC 64
 C11-1.5-9.5-N 12
 CP10-1-0.5-FL 12
 T11-1-M4 400
 W11-1-M4 200
 LS10-5-1-300-N 80
 Thread insert holder magnets 40
 M3 washers 12
 Item QTY
 M3 x 14 mm screw 12
 M4 large-diameter washers 400
 M4 small-diameter washers 100
 M4 x 10 mm screw 200
 M4 x 12 mm screw 200
 M4 x 16 mm screw 200
 M4 x 20 mm screw 200
 M4 x 25 mm screw 160
 M4 x 30 mm screw 160
 M4 x 35 mm screw 100
 M4 x 40 mm screw 100
 M4 x 45 mm screw 80
 M4 x 50 mm screw 80
 2, 2.5, and 3 mm hex keys 4 ea.
 2, 2.5, and 3 mm hex drivers 4 ea.
